Bomba neumática de doble diafragma de acero inoxidable 316 de 3/4 pulgada

Wetted Body Material: Stainless Steel 316

Center Air Chamber Material: Aluminum Alloy

Diaphragm material: Teflon (TFM), Polyethylene(UPE), Santoprene (STP)

It is suitable for the transportation of glycol, alcohol, sodium hydroxide, nitric acid, carbonic acid, fruit acid, enzyme, caustic soda, ammonia, asphalt, and some acid & alkali liquid, but not suitable for hydrochloric acid, dilute sulfuric acid...

Diafragmas:

Materiales	Rango de temperatura
UPE (U)	+5 to + 50°C
TFM (T)	-30 to +130°C
Stantoprene ® (O)	0 to + 80°C

Datos técnicos:

Tamaño del Puerto de Succión/Descarga	3/4” PT(BSP)
Entrada de aire	1/4” PT(BSP)
Salida de aire	3/8” PT(BSP)
Presión Mín.	0.5 Bar(kgf/cm²) ; 7.25psi
Presión máx.	8 Bar(kgf/cm²) ; 116psi
Mejor Rango de Presión de Entrada de Aire	1.5~3.5 Bar(kgf/cm²) ; 21.75psi~50.76psi
Volumen de Descarga por Ciclo	310 ml/cycle
Diámetro Máx. de partículas	⌀2.4mm
Consumo Máx. de Aire	750Liter/Per Min.; 26.49 Scfm/Per Min
Máx. de Succión en Húmedo	6.7 m
Dimensiones del Embalaje	26(L)cm x 24(W)cm x 35(H)cm
Peso Neto	11.5 KG
Tasa Máx. de Flujo	22.45 Gallon/Per Min. ; 85 Liter/Per Min.
Fluidos	Suitable almost all alkaline liquids and most acidic liquids, such as ethylene glycol, ethanol, sodium hydroxide, nitric acid, carbonic acid, fruit acids, enzymes, caustic soda, ammonia and asphalt. It also suitable wines and food sauces. Transport of some edible raw materials such as syrup, etc., but must be cleaned regularly. But it is not suitable for some special liquids such as dilute sulfuric acid, hydrochloric acid, hydrogen bromide, aqua regia, and chlorine. It can be used in the pharmaceutical industry, food industry, chemical industry, etc.
